DRONE DELIVERY SOLUTIONS

Drone delivery era is started and our drones are doing day-to-day delivery.

Delivering urgent orders to hard-to-reach areas and deliveries between post offices becomes reality. UVL Robotics has realized this potential and already set the clear course to create the Last mile delivery of tomorrow!

HOW DOES
IT WORK?
HOW DOES
IT WORK?
Online delivery order
Flight notification to regulatory authorities
Confirmation of the delivery order
Shipment delivered
Automatic delivery notification
Torok hybrid drone
Flight duration
240 min
Distance
150 km
Payload
up to 7 kg
Temperature range
-35*C - +45*C
Speed
47 km/h
DASHI
5250+ KM
Flight duration
3 hours
Distance
110 km
Payload
6 kg
Temperature range
-40*C - +40*C
Speed
50 km/h
Drone AI
Flight duration
25 min
Distance
20 km
Payload
2.5 kg
Temperature range
-20*C - +40*C
Speed
54 km/h
Autonomous
flights
Extremely long
flight time
High image resolution
for accurate analysis
Cold weather
conditions
Waste landfills
inspection
Port containers
inspection
Power lines
inspection
Search and
rescue operations
USE CASES

With fast and accurate drone delivery, the grocery segment is reaching customers that were previously out of reach due to increased traffic congestion and challenging geographic landscapes. The number of food delivery requests in the MENA region is increasing and UVL successfully copes with main necessity of business.

Specially designed containers that maintain the right temperature for food allow the order to be delivered to the customer on time and in the proper quality. In addition, we have developed a parcel locker, the cells of which optimize the temperature for each type of parcel.

Moreover, drone‘s delivery contributes to reduction of CO2 emission and decrease risks for couriers lives, who are desperately trying to deliver parcel in 15 minutes in the mountain area.

Oman Post and UVL Robotics conducted Drone Delivery Experiment - pilot experiment for drone solutions technology for 2 different use cases hosted at the Sultanate of Oman from 12th January 2020 to 18th January 2020.

In the scope of the agreed series of experiments between Oman Post and UVL Robotics parties jointly conducted the following: Delivery of parcel (weight ~2.5 kg) for Oman post in the area of Nizwa (Sultanate of Oman) where 2,735 meters were flown by the drone in 4 minutes 05 seconds in comparison with an average car drive time of 16 mins for the same distance.

Delivery of parcel (weight ~4.5 kg) for Oman post in the area of Muscat (Sultanate of Oman) where 3,250 meters return flight was conducted by the drone in a total of 8 minutes 50 seconds in comparison with an average car drive time of 12-15 mins to perform the same route.

Getting urgent medical equipment and medicines from A to B is not always a straightforward process, especially in areas with limited road infrastructure. UVL Robotics drones are deployed to help speed up the delivery process helping to get medical supplies where they are most needed.

UVL Robotics Drone Delivery Solutions for the healthcare industry is aimed to provide an uninterrupted supply chain with a high level of quality standards compliant with GDP guidelines and ensuring not only delivery from A to B but also last-mile storage inside medical spots equipped with temperature-controlled container cells to ensure maximum integrity of temperature-sensitive medicines and biological samples.

PRICE&DEMO
F.A.Q.
  1. What are the key features of the system?

    The System is a combination of key components:

    • Several types of drones for different distances and payloads, capable of flying within city limits and to remote areas
    • Parcel lockers equipped with battery swap mechanisms for drones and shipment storage and automatic sorting
    • Complete software integrations to control drone fleet, route planning and notifications to customers about shipment status
    • Comprehensive dashboards for full visibility of shipments, drones and parcel lockers status
    • Sizes of drones, parcel lockers and designs can be customized

    The system provides the full autonomous solution to the last-mile supply chain.

  2. What practical range (in km) can the UAV cover?

    Our electric drones can fly up to 20 minutes with a payload of up to 2.5 kg at a speed of 15 m/s. Hybrid drones can fly up to 180 minutes with a payload of up to 7 kg at a speed of 13 m/s.

  3. What are the weather conditions of the UASs?

    The UAS can be operated in the temperature range from -30*С to +39*С with a wind speed of up to 8 m / s.

  4. What are the key advantages of our solution?
    • Fully automated, minimal human intervention
    • Requires minimal training
    • It takes less than a week to set up a system at the clients’ site
    • Safety components such as safe route planning software and licenses
    • Cheaper than the standard car and courier combinations
    • Faster shipment deliveries
  5. Who is the owner of the software?

    We use a combination of our own + 3rd party software systems with our specialists doing APIs and SDK integrations adopting the systems for clients’ individual requirements.

  6. How does the principle of communication and navigation of UAS work?

    Navigation and fleet management software makes it easy to identify who is flying within a given airspace area, publish airspace information, set geofences, view flight plans, and respond to authorization requests automatically.

  7. How safe is the UAS?

    Flight safety is our top priority. The main UAS systems have different redundancy levels, ensuring high reliability and effectively reducing the probability of failure of control systems to zero. Unlike conventional drones, our UAVs will not return to the starting point in case of emergency situations, which can be dangerous, but will automatically decide to land at intermediate reserve points that are safe to land. These points are built by us in the route of the UAV.

  8. What is the cost of a UAS?

    We provide the system of delivery service by drones on a monthly lease model. Other forms of cooperation are discussed individually.

  9. What are the advantages of the service before the acquisition?

    We made our system easy to adapt and install in any part of the world, only minimal training is required to operate the system and our maintenance support center is 24/7 available to answer inquiries. We are constantly improving our product, taking into account the replication of new technologies and feedback from our customers, and consequently, we guarantee to our customers that we provide a service with the most modern technical solutions and software updates.

  10. How to start working with us?

    Call or email us. Our experts will analyze your task for the selection of the optimal configuration of the system.

x
WHITE PAPER
UVL Robotics publishes a very detailed study of the drone logistics market and its pathway to a scalable, globally accepted solution.
